Dahua PFM920I-6UN-C — 305m UTP CAT6 Cable

Características principales

• > 305 m (1000 ft)/carton UTP CAT6, power over Ethernet, compatible with one cable
• > High-purity oxygen-free copper conductor
• > Customized PVC outer sheath; CE CPR Eca flame retardant class certified
• 10-year warranty
• Conductor
• Material
• Oxygen free copper (99.97% purity)
• Diameter
• 0.53 mm ± 0.01 mm
• Insulation
• Material
• HDPE
• Min. Average Thickness
• 0.21 mm
• Diameter
• 0.95 mm ± 0.1 mm
• Color (4 Pairs)
• Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
• Separator
• Material
• PE
• Specification
• Translucent 4.5 × 0.4 mm
• Rip Cord
• Material
• Polyester
• Specification
• 500D
• Sheath
• Material
• PVC
• Min. Average Thickness
• 0.5 mm
• Diameter
• 6.0 mm ± 0.3 mm
• Color
• White
• Electrical
• Max. DC Resistance of a Single Conductor
• 8.7Ω/100 m
• Min. Insulation Resistance
• 5000MΩ·km
• Max. DC Resistance Unbalance
• 2% (pair intra), 4% (pairs inter)
• Dielectric Strength
• No breakdown with 1KV DC for 1 min
• Transmission
• Characteristic Impedance
• 100 ± 15Ω
• Near End Cross Talk
• Max. Attenuation
• Return Loss
• Mechanical
• Tensile Strength
• Sheath≥13.5 MPa, insulation≥16 MPa
• Elongation at Break
• Sheath≥150%, insulation≥300%
• Installation Bending Radius
• >8 times of outer cable diameter
• Conductor Elongation at Break
• ≥10%
• Environmental
• Shrinkage of Insulation
• ≤5%
• Color Migration Resistance of Insulation
• No migration
• Sheath Tensile Strength and Elongation at Break after Aging
• ≥12.5 MPa, ≥100%
• Low Temperature Bending Test
• No cracking after the test
• Heat Shock Test
• No cracking after the test
• Operating Temperature
• –20°C to +60°C (–4°F to 140°F)
• Installation Temperature
• 0°C to +50°C (32°F to 122°F)
• Storage Temperature and Humidity
• –10°C to +40°C (14°F to 104°F), <60% (RH)
• Security
• Vertical Fire Propagation Test
• Comply with IEC 60332-1-2
• Packaging
• Cable Length
• 305.0 m (1000.66 ft) ± 1.5 m (4.92 ft)
• Inner Carton Dimensions
• 416.0 mm × 412.0 mm × 220.0 mm (16.37″ × 16.22″ × 8.66″) (L × W × H)
• Packaging Method
• 305.0 m (1000.66 ft) a carton, one protection carton with 2 cartons inside
• Net Weight
• ≥10.5 kg (23.15 lb)
• Gross Weight
• ≥11.5 kg (25.35 lb)
• Compliance
• Executive Standards
• Q/DXJ 067-2019, EN50575-2014
• Certification
• Certification
• CPR Eca
• Transmission Characteristics
• (100 m at 20°C) (328.08 ft at 68°F)
• Frequency (MHz)
• Phase delay ≤ ns
• IL ≤ dB
• TCL≥ dB﹡
• EL TCTL≥ dB﹡
• NEXT ≥ dB
• PS NEXT ≥ dB
• 1
• n/s
• n/s
• 50.0
• 35.0
• n/s
• n/s
• 4
• 552.0
• 4.0
• 44.0
• 23.0
• 66.3
• 63.3
• 8
• 547.0
• 5.6
• 41.0
• 16.9
• 61.8
• 58.8
• 10
• 545.0
• 6.4
• 40.0
• 15.0
• 60.3
• 57.3
• 16
• 543.0
• 8.1
• 38.0
• 10.9
• 57.2
• 54.2
• 20
• 542.0
• 9.0
• 37.0
• 9.0
• 55.8
• 52.8
• 25
• 541.0
• 10.1
• 36.0
• 7.0
• 54.3
• 51.3
• 30﹡
• 540.6
• 11.0
• 35.2
• 5.5
• 53.1
• 50.1
• 31.25
• 540.0
• 11.3
• 35.1
• n/s
• 52.9
• 49.9
• 62.5
• 539.0
• 16.3
• 32.0
• n/s
• 48.4
• 45.4
• 100
• 538.0
• 21.0
• 30.0
• n/s
• 45.3
• 42.3
• 200
• 537.0
• 30.7
• 27.0
• n/s
• 40.8
• 37.8
• 250
• 536.0
• 34.8
• 26.0
• n/s
• 39.3
• 36.3
• Frequency (MHz)
• EL FEXT ≥ dB
• PS EL FEXT ≥ dB
• RL ≥ dB
• Delay skew ≤ ns
• Zc(Ω)
• 1
• n/s
• n/s
• n/s
• n/s
• n/s
• 4
• 56.0
• 53.0
• 23.0
• 45.0
• 100±15
• 8
• 49.9
• 46.9
• 24.5
• 10
• 48.0
• 45.0
• 25.0
• 16
• 43.9
• 40.9
• 25.0
• 20
• 42.0
• 39.0
• 25.0
• 25
• 40.0
• 37.0
• 24.3
• 30﹡
• 38.5
• 35.5
• 23.8
• 31.25
• 38.1
• 35.1
• 23.6
• 62.5
• 32.1
• 29.1
• 21.5
• 100
• 28.0
• 25.0
• 20.1
• 200
• 22.0
• 19.0
• 18.0
• 250
• 20.0
• 17.0
• 17.3
• Note:
• Executive standard for the above parameters: Q/DXJ 067-2019
• «n/s»=Not Specified
• «﹡»=Unless otherwise customer stated the test results default to not shown in test report but comply with standard
